MODEL: 5001
| MODEL NUMBER | 5001 |
| DIMENSIONS | |
| Overall Size (L*W*H) | 115*65*95cm |
| Folded Size (L*W*H) | 84.5*39*72cm |
| Seat Width | 45cm |
| Seat Depth | 43cm |
| Package Size | 81*41*76cm |
| POWER | |
| Motor Type | Brush |
| Quantity | 2pcs |
| Rated Power | 250W |
| Rated Voltage | 24V |
| Brake System | Hand Brake |
| Braking Distance | 0.3-0.5m |
| CONTROLLER | |
| Type | Joystick Controller |
| Input Voltage | 24V |
| Input Current | 35A |
| BATTERY | |
| Type | Lead-Acid Battery |
| Quantity | 1pcs |
| Rated Voltage | 24V |
| Capacity | Optional 12AH/20AH |
| FRONT WHEEL | |
| Size | 10" |
| Type | Solid Tire |
| Material | PU |
| BACK WHEEL | |
| Size | 16" |
| Type | Pneumatic Tire |
| Material | Rubber |
| OTHER PARAMETERS | |
| Driving Range | 12ah=12km / 20km=20km |
| Climbing Capacity | ≤13° |
| Safe Load | 120kg |
| Max.Forward Speed | 6km |
| Max.Backward Speed | 2km |
| Net.Weight | 34kg |
| Gross.Weight | 39kg |
| Charging Time | 7-8h |
